CHV Mini VRF 50/60Hz
32 201908
CHV Mini Series Service Manual
CHV-DH125W/R1
TC: Total Capacity (kW); PI: Power Input (kW) (Compressor + Outdoor fan motor)
Combination
(%)
(Capacity
index)
Outdoor Air
temperature
(
°
C DB)
Indoor temperature (
°
C WB)
DB: 20.8, WB: 14 DB: 23.3, WB: 16 DB: 25.8, WB: 18 DB: 27, WB: 19 DB: 28.2, WB: 20 DB: 30.7, WB: 22 DB: 32, WB: 24
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
130%
-5 8.8 1.24 9.3 1.31 9.6 1.35 9.8 1.38 10.0 1.41 10.3 1.45 10.6 1.49
-2 8.6 1.25 9.1 1.32 9.4 1.36 9.6 1.39 9.8 1.42 10.1 1.46 10.4 1.50
0 8.5 1.27 8.9 1.34 9.2 1.38 9.4 1.41 9.6 1.43 9.9 1.48 10.2 1.52
2 8.3 1.28 8.8 1.35 9.0 1.39 9.2 1.42 9.4 1.45 9.7 1.49 10.0 1.53
4 8.1 1.29 8.6 1.36 8.9 1.41 9.0 1.44 9.2 1.46 9.5 1.51 9.8 1.55
6 8.0 1.30 8.4 1.38 8.7 1.42 8.9 1.45 9.0 1.48 9.3 1.52 9.6 1.57
8 7.8 1.32 8.3 1.39
8.5 1.44 8.7 1.46 8.9 1.49 9.1 1.54 9.4 1.58
10 10.5 1.75 11.1 1.85 11.4 1.90 11.6 1.94 11.9 1.98 12.2 2.04 12.6 2.10
12
10.3 1.82 10.8 1.92 11.2 1.98 11.4 2.02 11.6 2.06 12.0 2.13 12.3 2.19
14
10.1 1.90 10.6 2.00 11.0 2.07 11.2 2.11 11.4 2.15 11.7 2.21 12.1 2.28
16
9.9 1.98 10.4 2.09 10.7 2.15 11.0 2.20 11.2 2.24 11.5 2.31 11.8 2.37
18
11.5 2.22 12.1 2.34 12.5 2.41 12.7 2.46 13.0 2.51 13.4 2.58 13.8 2.66
20
11.2 2.24 11.9 2.36 12.2 2.44 12.5 2.49 12.7 2.54 13.1 2.61 13.5 2.69
21
11.0 2.26 11.6 2.39 12.0 2.46 12.2 2.51 12.5 2.56 12.9 2.64 13.2 2.71
23
10.8 2.28 11.4 2.41 11.8 2.49 12.0 2.54 12.2 2.59 12.6 2.66 13.0 2.74
25
10.6 2.31 11.2
2.43 11.5 2.51 11.8 2.56 12.0 2.61 12.4 2.69 12.7 2.77
27
13.0 2.88 13.8 3.04 14.2 3.13 14.5 3.20 14.8 3.26 15.2 3.36 15.6 3.45
29
12.8 2.91 13.5 3.07 13.9 3.16 14.2 3.23 14.5 3.29 14.9 3.39 15.3 3.49
31
12.5 2.94 13.2 3.10 13.6 3.20 13.9 3.26 14.2 3.33 14.6 3.42 15.0 3.52
33
12.3 2.97 13.0 3.13 13.4 3.23 13.6 3.29 13.9 3.36 14.3 3.46 14.7 3.56
35
12.0 3.00 12.7 3.16 13.1 3.26 13.4 3.33 13.6 3.39 14.0 3.49 14.4 3.59
37
11.8 3.01 12.5 3.18 12.8 3.28 13.1 3.34 13.4 3.41 13.8 3.51 14.2 3.61
39
11.2 2.95 11.8 3.11 12.2 3.21 12.5 3.28 12.7 3.34 13.1 3.44 13.4 3.54
41
10.6 2.89 11.2 3.05 11.6 3.15 11.8 3.21 12.1 3.28 12.4 3.37 12.8 3.47
43
10.1 2.83
10.7 2.99 11.0 3.08 11.2 3.15 11.5 3.21 11.8 3.31 12.1 3.40
45
9.6 2.75 10.1 2.90 10.5 2.99 10.7 3.05 10.9 3.11 11.2 3.21 11.5 3.30
48
9.1 2.61 9.6 2.76 9.9 2.84 10.1 2.90 10.3 2.96 10.6 3.05 11.0 3.13
50
8.7 2.40 9.2 2.54 9.4 2.62 9.6 2.67 9.8 2.72 10.1 2.80 10.4 2.88
52
8.2 2.21 8.7 2.33 9.0 2.41 9.2 2.46 9.3 2.50 9.6 2.58 9.9 2.65
55
7.8 2.03 8.3 2.15 8.5 2.21 8.7 2.26 8.9 2.30 9.1 2.37 9.4 2.44
120%
-5 8.6 1.23 9.1 1.30 9.4 1.34 9.6 1.37 9.8 1.39 10.1 1.43 10.4 1.47
-2 8.5 1.24 8.9 1.31 9.2 1.35 9.4 1.38 9.6 1.41 9.9 1.45 10.2 1.49
0 8.3 1.25 8.8 1.32 9.0 1.37 9.2 1.39 9.4 1.42 9.7 1.46 10.0 1.50
2 8.1 1.27 8.6 1.34 8.9 1.38 9.1 1.41 9.2 1.44 9.5 1.48 9.8 1.52
4 8.0 1.28 8.4 1.35 8.7 1.39 8.9 1.42 9.1 1.45 9.3 1.49 9.6 1.54
6 7.8 1.29 8.3 1.36 8.5 1.41 8.7 1.44 8.9 1.46 9.1 1.51 9.4 1.55
8 7.7 1.31 8.1 1.38 8.4 1.42 8.5 1.45 8.7 1.48 9.0 1.52 9.2 1.57
10 10.3 1.73 10.9 1.83 11.2 1.89 11.4 1.92 11.6 1.96 12.0 2.02 12.3 2.08
12
10.1 1.80 10.6 1.90 11.0 1.96 11.2 2.00 11.4 2.04 11.8 2.11 12.1 2.17
14
9.9 1.88 10.4 1.98 10.8 2.05 11.0 2.09 11.2 2.13 11.5 2.19 11.9 2.26
16
9.7 1.96 10.2 2.07 10.5 2.13 10.8 2.18 11.0 2.22 11.3 2.28 11.6 2.35
18
11.3 2.19 11.9 2.32 12.3 2.39 12.5 2.44 12.8 2.49 13.1 2.56 13.5
2.63
20
11.0 2.22 11.6 2.34 12.0 2.41 12.3 2.46 12.5 2.51 12.9 2.59 13.2 2.66
21
10.8 2.24 11.4 2.36 11.8 2.44 12.0 2.49 12.3 2.54 12.6 2.61 13.0 2.69
23
10.6 2.26 11.2 2.39 11.5 2.46 11.8 2.51 12.0 2.56 12.4 2.64 12.7 2.71
25
10.4 2.28 11.0 2.41 11.3 2.49 11.6 2.54 11.8 2.59 12.1 2.66 12.5 2.74
27
12.8 2.85 13.5 3.01 13.9 3.10 14.2 3.17 14.5 3.23 14.9 3.32 15.3 3.42
29
12.5 2.88 13.2 3.04 13.6 3.13 13.9 3.20 14.2 3.26 14.6 3.36 15.0 3.45
31
12.3 2.91 13.0 3.07 13.4 3.17 13.7 3.23 13.9 3.30 14.3 3.39 14.7 3.49
33
12.0 2.94 12.7 3.10 13.1 3.20 13.4 3.26 13.7 3.33 14.1 3.43 14.5 3.52
35
11.8 2.97 12.5 3.13 12.9 3.23 13.1 3.30 13.4 3.36 13.8 3.46
14.2 3.56
37
11.6 2.98 12.2 3.15 12.6 3.25 12.9 3.31 13.1 3.38 13.5 3.48 13.9 3.58
39
11.0 2.92 11.6 3.08 12.0 3.18 12.2 3.25 12.5 3.31 12.8 3.41 13.2 3.51
41
10.4 2.86 11.0 3.02 11.4 3.12 11.6 3.18 11.8 3.24 12.2 3.34 12.5 3.44
43
9.9 2.81 10.5 2.96 10.8 3.06 11.0 3.12 11.2 3.18 11.6 3.27 11.9 3.37
45
9.4 2.72 10.0 2.87 10.3 2.96 10.5 3.02 10.7 3.08 11.0 3.18 11.3 3.27
48
9.0 2.59 9.5 2.73 9.8 2.82 10.0 2.87 10.2 2.93 10.5 3.02 10.7 3.10
50
8.5 2.38 9.0 2.51 9.3 2.59 9.5 2.64 9.6 2.70 9.9 2.78 10.2 2.85
52
8.1 2.19 8.5 2.31 8.8 2.38 9.0 2.43 9.2 2.48 9.4 2.55 9.7 2.63
55
7.7 2.01 8.1 2.13 8.4 2.19 8.5 2.24 8.7 2.28 9.0
2.35 9.2 2.42
