CHV Mini Series Service Manual

CHV Mini VRF 50/60Hz

1. Indoor and Outdoor Unit Capacities

1.1 Indoor Units

Table 1-1.1: Standard indoor unit abbreviation codes

Abbreviation

code

Type

G Wall-mounted

LD Floor & Ceiling

TA Low ESP Short Ducted

TB Medium ESP Ducted

TH High ESP Ducted

Abbreviation

code

Type

Q1 One-way Cassette

Q2 Two-way Cassette

Q4 Compact four-way Cassette

Q Four-way Cassette

QR Round-flow Cassette

F Floor Standing

Table 1-1.2: Standard indoor unit capacity range

Capacity

index

Q1 Q2 Q4

TA TB TH

2.2 22

—

— —

—

2.8 28

—

— — —

—

3.6 36

—

— — —

—

4.5 45

45 45 45

— — —

45 45 45

—

5.6 56

56 56

—

56 56

—

56 56 56

—

7.1 71

71 71

—

71 71

—

71 71 71 71 71

8.0 80

—

80 80

—

80 80

—

80 80

9.0 90

— — —

90 90

—

90 90

10.0 100

— — —

100 100 100

— — —

100 100

11.2 112

— — —

112 112 112

—

112

— — —

12.0 120

— — — — — — — — —

120 120

12.5 125

— — —

125 125 125

— — — — —

14.0 140

—

140 140 140

—

140

— —

—

15.0 150

— — — — — — — — —

150 150

16.0 160

— — —

160 160 160

—

160

— — —

1.2 Outdoor Units

Table 1-1.3: Outdoor unit capacity range

Capacity 8kW 10kW 12.5kW 14kW 16kW

Model CHV-DH080W/R1 CHV-DH100W/R1 CHV-DH125W/R1 CHV-DH140W/R1 CHV-DH160W/R1
