R410A DC Inverter Multi-split Technical Manual Indoor Units
15
GD Chigo Heating & Ventilation Equipment Co., Ltd.
4. Service Space
A
40
90
40
45
65
Right rear side
refrigerant pipe hole
B
Installation plate
Indoor unit outline
150 mm or more to
ceiling
120 mm or
more to wall
Left rear side
refrigerant pipe hole
120 mm or
more to wall
65
Model
A(mm)
B(mm)
≤12000Btu/h
790
280
≥18000Btu/h
900
296
