Chigo CSG-07HVR1(84) User Manual

R410A DC Inverter Multi-split Technical Manual Indoor Units
16
GD Chigo Heating & Ventilation Equipment Co., Ltd.
5. Wiring Diagrams
CSG-07HVR1CSG-09HVR1CSG-12HVR1
CPU
EEPROM
Memory
Type
DISPLAYT1
Cool SW
Fan backSwing
Trans in
PG
Trans out
N
L
T2
T2B
choice
OFF
ON
1 2
PG
Motor
STEP
Motor
N
L
S
Terminal block：
POWER
Communication
S
6 LINE
TO outdoor
earth connection
Evaporator
Remark：
1、 Make Memory short-circuit is a power outage memory otherwise for nothing
2、According to the specific models to dial the code
Light board
BR YE/GN BK BL
BR YE/GN BK BL
Type
choice 2
OFF
ON
1 2
PT3 PT2
PT1
Outlet
Middle
sensor
sensor
sensor
Ambient
temperature
Type
1.8-2.2KW
2.3-2.8KW
2.9-3.6KW 2.9-3.6KW
choice
POWER
OFF
ON
1 2
OFF
ON
1 2
OFF
ON
1 2
OFF
ON
1
2
Type
M87 M84
choice2
Models
OFF
ON
1 2
OFF
ON
1 2
M107
OFF
ON
1 2
