Chigo CSG-07HVR1(84) User Manual

R410A DC Inverter Multi-split Technical Manual Outdoor Units
69
GD Chigo Heating & Ventilation Equipment Co., Ltd.
1.4 Point check function
NO.
Display
Instruction
Normal Display
The current running frequency
Note 1
1
The total demand for indoor units
The total demand that the indoor send over
2
operating mode
0，1，2，3，4,5（note 2）
3
The real-time output capacity of the outdoor unit
The actual ability output (after various
protection)
4
Fan state
（note 3）
5
T2 average/T2B average
The actual value(note 4)
6
T3（the tube temperature of outdoor condenser）
The actual value
7
T4( the outdoor environment temperature)
The actual value
8
T7(the inverter exhaust temperature)
The actual value
9
The one side for inverter
The actual value
10
The another side for inverter
The actual value
11
EXV A opening degree
The actual value
12
EXV B opening degree
（Note 5）The actual value
13
EXV C opening degree
（Note 5）The actual value
14
EXV D opening degree
（Note 5）The actual value
15
The indoor unitstemperature for A system
Cooling T2B，heating T2
16
The indoor unitstemperature for B system
Cooling T2B，heating T2
17
The indoor units temperature for C system
Cooling T2B，heating T2
18
The indoor units temperature for D system
Cooling T2B，heating T2
19
The sets of the indoor units that can communicate normally
The actual value
20
---
Point check over
Note 1: normal shows.When standby , it indicates the sets of indoor units. When the compressor begin to
operate,it indicates operating frequency of the compressor. When protection or failure appear , it shows
protecting code or failure code. When there is some protection or failure code, it will repeatlydisplay protection
or failure code.
Note 2: operating mode (shutdown:0 supply air:1 cooling/dehumidification:2 heating:3 rated cooling:4
rated heating: 5)
Note 3: operating wind speed (shutdown:0 low speed:1 high speed:2)
Note 4:when cooling,it shows the average temperature T2B, when heating,it shows the average temperature
T2.
Note 5: electronic expansion valves opening degree divided by 8 shows. Such as 480 P is revealed to 60.
