NVF5 Series User Manual Chapter 6 Parameter Function Description
Frequency highest Limit：Limit max. output frequency，motor is not allowed to run over
the highest limit frequency；
Frequency Lowest Limit：Limit min. output frequency，motor is not allowed to run
below the lowest limit frequency；
Max. Output Frequency：Limit the Max. output frequency.
Code Name Default Setting Range Description
F0.07
Max. Output
Frequency
50.00 Hz F0.08 ～ 600.00Hz -
F0.08
Maximum
Frequency
50.00 Hz F0.09 ～ F0.07 -
F0.09
Minimum
Frequency
0.00 Hz 0.00Hz ～ F0.08 -
6.3 Start and Stop Setting
6.3.1 Start Mode
NVF5 has three starting modes: Starting from starting frequency, first braking then
starting from starting frequency, speed tracking and restart.Set parameter F1.00 to select
NVF5 start mode.
Code Name Default Setting Range Description
F1.00
Start Mode Selection
0 0 ～ 2
0 :
Start from the
starting frequency
1 : First brake and
then start from
the starting
frequency
2 : Speed tracking
(including
direction
discrimination)
and then start
F1.01
Direct starting
frequency
0.00Hz （0.00～ 10.00）Hz -
F1.02
Starting frequency
Holding time
0. 0s （0.0 ～ 100.0）s -
F1.03
DC braking current
Before starting
0.0% （0.0 ～ 100.0）%
100% （ Inverter
Rated Current）
F1.04
DC brakin time
Before starting
0.0s （0.0～ 100.0）s -
 Starting from starting frequency
