4.4 PARTS IDENTIFICATION
1) Main Switch
2) Indicator lights
3) Belt conveyor
4) Belt centering screw
5) Belt tensioning screw
6) Conveyor belt raising wheel
7) Shutter knob
8) Caster with brake
9) Panel blocking hooks
10) Exhaust fumes extractor
11) Ventilation motor
