4. FEATURES
4.1 DESCRIPTION AND PURPOSE OF THE MACHINE
“ACE” is an elevated circulation hot air tunnel dryer. It has been designed to dry and polymerize fabrics printed with digital
printers using water based inks. Do not use with inks containing flammable solvents.
Electric heating was chosen because it involves fewer installation and maintenance problems.
The temperature is adjusted by a precision thermostat and by a long lasting static relay control system. In this manner,
the temperature never exceeds the set value thus preventing damage to delicate fabrics. The air exchange is adjusted to
discharge steam and promote drying.
Hot air circulation system is specially designed and employs high yield low noise reverse blades. Outflow nozzles direct
the air onto the product perpendicularly and at high speed. Filters on each fan render the system efficient. The passage
height can be adjusted between 30 and 110mm.
Different conveyor belt configurations are available In the version with the outward and return belt, loading and unloading
are at the same location such that one person can follow the whole process.
The return passage occurs within the dryer, this means that the drying time is effectively doubled. The insulation covering
the dryer reduces heating of the room where the dryer is located and also overall power consumption.
4.2 TECHNICAL DATA
