Ⅳ、Web Function Instruction
 One Page Quick Setup
 Function instruction of STATIC IP
Function Description
IP Address Set the IP address of the BF-430，default setting is 192.168.168.125
Subnet mask Set the subnet mask of the BF-430，default setting is 255.255.255.0
Gateway Set the gateway of the BF-430，default setting is 192.168.168.254
Primary DNS Set the DNS of the BF-430，default setting is 168.95.1.1
Serial Port Mode
Serial Type
Set the serial type, RS232 and RS485 for setting , default setting is
RS232
Baud Rate
1.Set serial port baud rate, the parameters can be selected：1200、2400、
4800、9600、19200、38400、57600、115200、230400 and Others
2.After selecting Others , fill custom baud rate into the user defined
3.Default setting is 19200
Operation Mode
Connection Mode
There are 4 modes to set into connection mode, such as：
 TCP Server
 TCP Client
 UDP Server
 UDP Client
Connection Port Number Set BF-430 connection port number, default setting is 50000
Remote Host IP Address
(For Client Only)
1.Set the remote host IP address, the default setting is 0.0.0.0
2.For Client Only
