CHIYU BF-430 - One Page Quick Setup (PPPoE); Function Instruction of PPPoE

- 12 -
 Function instruction of PPPoE
Function Description
User Name Fill in the user name, up to 47 characters
Password Fill in the password, up to 35 characters
Service Name (optional) Fill in the service name (optional), up to 47 characters
Close Connection when
Idle Time Over
 Default setting is 0 second, the range is from 0 ~ 4294967295
 Keep the connection of
BF-430 and ISP always must set the no into
0 or the connection with PPPoE will be disabled when Idle time over.
PPPoE with Fixed IP
Address
 After selecting ENABLE , fill in fixed IP
 Default setting is DISABLE
 optional
Serial Port Mode
Serial Type
Set the serial type, RS232 and RS485 for setting , default setting is
RS232
Baud Rate
1.Set serial port baud rate, the parameters can be selected：1200、
2400、4800、9600、19200、38400、57600、115200、230400 and
Others
2.After selecting Others , fill custom baud rate into the user defined
3.Default setting is 19200
Operation Mode
Connection Mode
There are 4 modes to set into connection mode, such as：
 TCP Server
 TCP Client
 UDP Server
 UDP Client
Connection Port Number Set BF-430 connection port number, default setting is 50000
Remote Host IP Address
(For Client Only)
1.Set the remote host IP address, the default setting is 0.0.0.0
2.For Client Only
