Chord Hugo M Scaler User Manual

Chord Electronics
Hugo M Scaler | Manual
_
The rear panel houses
the device’s wide-ranging
connectivity, inputs and outputs.
The Hugo M Scaler also features
a dual-data output, for optimum
use with selected Chord
Electronics’ DACs.
When installing any cable, you
must make sure that they securly
click into place, especially
optical.
3.1 Getting to know Hugo M Scaler
& drivers
3.2 The front panel
3.3 The top panel
3.4 The rear panel
3.5 The remote control
The rear panel 3.4
16 // 30
WARNING: Do not
use any other power
supply other than
that supplied. Doing so will
invalidate your warranty.
Optical input 2 BNC S/PDIF output
BNC output 1
USB inputBNC input 1
BNC output 2
BNC input 2
DC 15V input Optical input 1 Optical Output

Chord Hugo M Scaler Specifications

General

Brand	Chord
Model	Hugo M Scaler
Category	Media Converter
Language	English
