Chord ULTIMA PRE - Front Panel Features

Chord Electronics
ULTIMA PRE | Manual
_
The front panel features the
Display, Volume and Balance
dials and the menu buttons.
It also features the IR window
which is used withe the remote
and 2 1/4 heaphone jacks.
3.1 Getting to know ULTIMA PRE
3.2 The front panel
3.3 The top panel
3.4 The rear panel
3.5 The remote control
The front panel 3.2
13 // 34
Display
Volume dial
Balanced dial
Menu buttons
IR window
Headphones Jack
Power button
Hight and low
frequency dials
