Section 3: Operation
013-100199-04 3-71.
The Status LED Codes
If the status code display on the back of the projector shows one of the following
values, you have encountered a likely system error requiring the attention of a
qualified service technician (see System Warnings and System Errors, above).
Acknowledge and clear the error with
Exit
Exit
from presentation level, or try
resetting the projector by powering it off and on again, cooling when necessary.
Consult Table 3.5 and contact your dealer if the problem persists.
The specific code number identifies the source of the error detected, and is
particularly useful in cases where the projector is far away. For example, the code
“27” means the lamp could not be turned on. Error codes for this projector are listed in
Table 3.5 below.
Table 3.5 Error Codes
Code Description
GENERAL
12 Software bug. Contact dealer/factory.
13 CRC error in flash ROM. Download new software.
14 Engineering-only programming is complete. Call Christie, replace TIPM.
15 Attempting to download code without being in boot mode
16 Invalid interrupt. Power off/on. If it persists, contact dealer/factory.
17 User forced system to stay in boot mode
18 Jumper for programming boot not installed
LAMP FAILURES
20 Lamp turned on unexpectedly (fault related to ballast)
21 Lamp airflow low, overheating imminent
23 Cannot read valid ballast ID
26 Lamp Interlock: lamp door open, lamp not installed
27 Can’t turn lamp on
28 Lamp turned off unexpectedly
29 Lamp ballast overheated
POWER AND COOLING
46 Red DMD heatsink overheated
47 Green DMD heatsink overheated
48 Blue DMD heatsink overheated
49 Prism overheated
4C Projector shutdown due to critical error
C0 Lamp blower failure (lamp not turned on)
51 LVPS fan failed (Fan 1)
52 LVPS/ Red cooling fan failed (Fan 2)
53 DC lamp fan failed in 500W / 1kW models (Fan 3)
54 Red DMD heatsink fan failed on 1kW and 1.2kW models (Fan 4)
55 Green DMD heatsink fan failed on 1kW and 1.2kW models (Fan 5)
56 Blue DMD heatsink fan failed on 1kW and 1.2kW models (Fan 6)
57 TIPM fan failed (Fan 7)
58 TIPM fan failed (Fan 8)
TIPM (Image Processor)
60 Boot code CRC failed
61 Unable to program DigMux PLD
62 Unable to program Control PLD
63 Unable to program Bubks PLD
64 Unrecognized ROM type
65 Write to flash ROM failed
66 TIPM failure
67 Downloaded code will not fit
68 Scaler communication problem
BUILT-IN KEYPAD
70 Unable to access EEPROM on the built-in keypad
71 EEPROM memory re-initialization on the built-in keypad
PANEL DRIVER AND FORMATTER
80 Unrecognized Panel Driver
81 Unable to program device on Panel Driver
82 TI flash download failure
83 TI flash download failure
84 TI flash download failure
85 TI-I2C write failure
86 One or more Formatters not responding — Probable Formatter s/w fault
87 Formatter reports RDRAM failure
