Christopeit Sport Basic Concept - Page 14

14
Illustration Designation Dimensions Quantity Attached to ET number ET number ET number
No. mm illustration No. Art-Nr.9881 Art-Nr.98811
46 Hexagonal bolt M8x16 1 8+11 39-9823-CR 39-9823-CR 39-9823-CR
47 Hexagonal bolt M6x35 8 3+15+22+23 39-9979-CR 39-9979-CR 39-9979-CR
48 Hexagonal bolt M8x55 1 3+11 39-10056-CR 39-10056-CR 39-10056-CR
49 Self-locking nut M10 11 38+39+40+42+43 39-9981-CR 39-9981-CR 39-9981-CR
50 Self-locking nut M 8 1 48 39-9818-CR 39-9818-CR 39-9818-CR
51 Locking pin 1 2+3 36-9881-11-BT 36-9881-11-BT 36-9881-11-BT
52 Washer 10//20 22 38+39+40+42+43 39-9989-CR 39-9989-CR 39-9989-CR
53 Washer 8//16 5 41+46+48 39-9862-CR 39-9862-CR 39-9862-CR
54 Washer 6//12 13 47+60+61+57 39-10007-CR 39-10007-CR 39-10007-CR
55 Allen screw 1 44 36-9881-12-BT 36-9881-12-BT 36-9881-12-BT
56 Plastic spacer 2 24 36-9588-18-BT 36-9588-18-BT 36-9588-18-BT
57 Philips screw M5x20 3 26+63 39-9997 39-9997 39-9997
58 Stop slide 1 24 33-9881-17-SI 33-9181-17-BR 33-9881117-SW
59 Reinforcing plate 2 1 33-9881-18-SI 33-9181-18-BR 33-9881118-SW
60 Securing clip, left 1 1 33-9881-16-SI 33-9881-16-SI 33-9881-16-SI
61 Securing clip, right 1 1 33-9881-20-SI 33-9881-20-SI 33-9881-20-SI
62 Self-locking nut M6 2 60+61 39-9861-CR 39-9861-CR 39-9861-CR
63 Rubber damper, small 1 58 36-9582-03-BT 36-9582-03-BT 36-9582-03-BT
64 Square stopper 2 14+58 39-10089 39-10089 39-10089
65 Handgrip nut M10 2 43 36-9881-17-BT 36-9881-17-BT 36-9881-17-BT
66 Latissmus bar rest 1 24 33-9881-19-SI 33-9181-19-BR 33-9881119-SW
67 Cable drum cover 2 18 36-9588-26-BT 36-9588-26-BT 36-9588-26-BT
68 Carton label 1 36-9881-22-BT 36-9181-06-BT 36-9181-06-BT
69 Tool set 1 36-9881-14-BT 36-9881-14-BT 36-9881-14-BT
70 Assembly and operating instructions 1 36-9881-24-BT 36-9881-24-BT 36-9881-24-BT
71 Carton 1 36-9881-16-BT 36-9881-16-BT 36-9881-16-BT
Parts List – Spare Parts List
Basic Concept Order No.:
9881 (silver), 9181 (brown), 98811 (black)
