Chroma 19020 Quick Start Guide

Multi-Channel Sync Hipot Tester 19020/19020-4/19021/19022/19022-4
Quick Start Guide
1
1. Introduction
1.1 Product Overview
■ The Multi-Channel Sync Hipot Testers are high quality devices specially
designed to test the hipot leakage current and insulation resistance
automatically for electrical and electronic equipment.
■ For withstand voltage test, the output power of each channel for
19020/19020-4 is AC: 50VA (5kV, 10mA) /DC: 30VA (6kV, 5mA), for 19021
is AC: 48VA (6kV, 8mA) and for
19022/19022-4 is DC: 28VA (8kV, 3.5mA).
Thus they can be used to perform withstand voltage tests on electronic,
electrical equipment as well as on components.
■ For insulation resistance test, the range it can show is 0.1MΩ ∼ 50GΩ and
the test voltage is 50V~1000V that can be set as desired. (Note: Only 19021
can conduct AC withstand voltage test.)
■ The Hipot Tester uses a clear display to show all settings, time, current,
voltage, resistance and memory channel no., etc without the need to
memorize the parameters set previously.
■ The Hipot Tester has equipped the device to identify pass or fail products as
well as to output signals of test result and to remote control other devices.
It has GPIB, HANDLER and RS232 interfaces that are of advantage to
automatic test system. This Tester equipped with assorted devices
mentioned above is capable of performing highly efficient and accurate tests
for electrical, electronics equipment and components.
1.2 Standard Package
Item Name Qty Description
US Power Cord 1
USA standard 180 degree straight head power cord
with length 1.8 meter, 15A
15A Fuse 2 15A SLOW
CANBUS Cable 1
PHONE CABLE 6P6C to connect multiple devices,
length 1 meter
D-SUB Cable 1
D-SUB-25P-MALE*2 to connection multiple devices,
length 1 meter
High Voltage
Cable
Note 2
Single head high voltage terminal + 20kV high voltage
cable, length 3.1 meters
RTN/LOW Cable
Note 2
Single head BNC(MALE)+RG-174, length 3 meters
Quick Start Guide 2 English and Traditional Chinese version.
User’s Manual CD 1
CD for user’s manuals in English and Traditional
Chinese
Note
1. When additional item is required, just inform Chroma the item
name.
