Multi-Channel Sync Hipot Tester 19020/19020-4/19021/19022/19022-4
Quick Start Guide
12
(9) GND Terminal : It is the safety grounding terminal. Please use an
appropriate tool to connect it to earth properly. If it is
not properly grounded, the Tester chassis may contain
high voltage when the power circuit or any device’s
cable is shorted with the grounding terminal, and it is
very dangerous as anyone who touches it may cause
electric shock incident. Therefore, the safety ground
terminal must be connected to earth properly.
(10) AC Input : It contains a three-wire AC power socket. The AC
power required by the Tester is supplied by this power
socket. The power socket or connecting cable can be
interrupt device.
(11) High Voltage Module : It is the combination of high voltage output circuits. Be
sure the anchor screws are secured.
(12) High Voltage Output Channel : It is the high potential terminal for high
voltage output. The output terminal that belongs to
high potential output terminal usually has high voltage
output. Thus, it is very dangerous. Do not touch it
especially when the DANGER LED is on with high
voltage output.
(13) RTN/LOW Channel : It is a common test terminal that is the reference
terminal for high voltage test. It is the low potential
terminal that almost equals to chassis grounding
terminal.
3.3 Conducting Test
3.3.1 How to Get in PROGRAM Setting Screen
Press MAIN INDEX in any screen and press ▲, ▼ to move the highlight to
[PROGRAM] as the screen shows below.
