Multi-Channel Sync Hipot Tester 19020/19020-4/19021/19022/19022-4
Quick Start Guide
AIN INDEX
1.
ROGRAM
2.
TORE/RECALL
REMOTE LOCK CORR ERROR
Press ENTER to enter into the program setting screen.
13
PROGRAM
01. TEST STEP 1 UP
02. TEST MODE AC
03. VOLTAGE OFF DOWN
04. HIGH LIMIT 0.500 mA
05. LOW LIMIT OFF NEW
06. ARC LIMIT OFF
07. TEST TIME 3.0 sec INSERT
08. RAMP TIME OFF
09. FALL TIME OFF DELETE
10. CHANNELS DEFAULT
EXIT
1-10 REMOTE LOCK CORR ERROR
(1) Position 1 shows the list of setting items of each parameter.
(2) Position 2 shows the settings of each parameter. Press ▲, ▼ to move the
highlight to the parameter to be set in order to input the settings.
(3) Position 3 is the “Function Keys” display area that is varied with the setting
items of each parameter. Press F1~F6 to set the parameter.
Position 4
Position 2Position 1 Position 3
To Next Page
