Local Operation
Normal Mode
(1) Press the desired numeric keys of 1 , 3 , 5 , . , 2 , ENTER to set V=135.2V.
(2) Press ▲ or ▼ key repeatedly, or keep pressing any of them until the desired
value, V=135.2V, is shown on the LCD. Then, press ENTER to confirm.
Increase or decrease value is done through the use of the farthest right digit.
If a parameter is modified, the user has to press ENTER to update the
current data and save them into memory, otherwise the old data will
remain when he exits from the machine.
Editing Mode Display of Cursor
In editing mode the user can set parameters V=135.2_ F= 60.0
immediately without pressing ENTER to confirm.
The mode only allows the user to set V or F parameter.
When the user moves the cursor to V parameter, and
presses Edit to enter into the editing mode, the cursor
will show as right:
Set the output voltage as 132.2V as follows:
Move the cursor to the position of digit 5 using , and press 2 to set V=132_.2. Press
Edit to enter into editing mode. Editing mode is useful when you want to change V or F
parameter only one digit, or to set output V or F in step change. In this mode the user can
increase or decrease the value of current position by pressing
▲ , ▼ or PRG too. Press
Edit again to quit from editing mode.
3.2.3 Output Setting
The Output Setting on the screen is the main operation menu in the AC source, which accepts
AC output parameters, including V, F Sync. source, etc. In this menu the user can activate
the AC source by pressing the soft key of
RUN, and obtain the measured results at the
terminals of the devices under test.
