Programmable AC Source 6460/6463/6490 User’s Manual
3-16
power supply is lower than specification.
OTP INT
It is over temperature protection, and will be enabled when the
internal temperature of the AC source is too high.
OPEN INT
It is feedback open protection.
S.OCP INT
It is over current protection, and means that the output stage is over
the current limit user programs.
S.OPP INT
It is over power protection, and means that the output stage is over
the power specification which is checked by software.
NP INT
It is negative power protection, and means that the output stage has
negative power.
dV INT
The protection happens when there is a large difference between
the set voltage and the measured one.
If any output protection mentioned above is triggered to hold normal output, please remove
the errors, then, press
ENTER, and hold the key for two seconds to unlock the output
protection so as to resume the normal operation.
