Appendix A Pin Assignment of User Interface
A-1
Appendix A Pin Assignment of User
Interface
25-Pin D-Type Male Connector:
Pin No.
Signal
Pin No.
Signal
Description
1
GND
14
System Used
2
GND
15
System Used
3
GND
16
System Used
4
GND
17
System Used
5
GND
18
System Used
6
GND
19
System Used
7
GND
20
System Used
8
GND
21
System Used
9
GND
22
-------
10
GND
23
TRIG
Trigger
11
GND
24
TRANS
Transient
12
System Used
25
AC ON
Output enable
13
System Used
