Chromalox IntelliTrace ITC 1 User Manual

22
Parameter Defaults, Min., Max. & Range & User Settings
Screen Menu & Parameter
6. Comms Menu Default Min. Max. Also User Settings
Baud Rate 9.6k 2.4k, 4.8k, 9.6k, 19.2k, 38.4k, 56.0k
Parity None Even Odd None
ModBus ID 1 1 255
IP Address Optional Feature
DHCP Use Use Do Not Use
7. Systems Menu Default Min. Max. Range User Settings
Firmware Version Current Firmware Version
Button Sound On Off On
Units Fahrenheit Fahrenheit Celsius
Temperature Sensing 1 Single Single, Average, Low, High
Temperature Sensing 2 Single
Single, Average, Low, High,
Use 1 RTD to control both circuits
Failed Sensor Output 1 50% 0% 100%
Failed Sensor Output 2 50% 0% 100%
Password Level 1
Password InputsPassword Level 2
Password Level 3
Alarm State
Normally
Closed
Normally
Open
Normally
Closed
Restore to Default Disabled Up / Down Up / Down
