Chromalox IntelliTrace ITC 1 User Manual

21
Default Settings
Below is the ITC parameter settings chart organized by Menu Screen. It includes the default, minimum, maximum
and / or the range of settings, where applicable.
The chart is for either 1 or 2 circuit units.
Parameter Defaults, Min., Max. & Range & User Settings
Screen Menu & Parameter
3. Temperature Menu Default Min. Max. Also User Settings
Temp Setpoint 1 45˚F -80˚F 1,100˚F
Lo Temp Alarm 1 40˚F -80˚F 1,050˚F Off
Hi Temp Alarm 1 180˚F -80˚F 1,150˚F Off
Temp Setpoint 2 45˚F -80˚F 1,100˚F
Lo Temp Alarm 2 40˚F -80˚F 1,050˚F Off
Hi Temp Alarm 2 180˚F -80˚F 1,150˚F Off
4. Current Menu Default Min. Max. Also User Settings
Low Current Alarm 1 0.1 A 0.1 A 50.0 A Off
Hi Current Alarm 1 40.0 A 0.1 A 50.0 A Off
GFEP Setpoint 1 30 mA 30 mA 150 mA
GFEP Alarm/Trip 1 Alarm Only Alarm Only, Alarm & Trip; Latching & Non Latching
Low Current Alarm 2 0.1 A 0.1 A 50.0 A Off
Hi Current Alarm 2 40.0 A 0.1 A 50.0 A Off
GFEP Setpoint 2 30 mA 30 mA 150 mA
GFEP Alarm/Trip 2 Alarm Only Alarm Only, Alarm & Trip; Latching & Non Latching
5. Control Menu Default Min. Max. Also User Settings
Auto Control Mode 1 PID On / Off PID
Auto / Manual / Off 1 Auto 0 100 Off
Deadband 1 10 2 100
Autotune 1 Off Off On
Proportional Band 1 20 1 100
Integral 1 500 0 9999
Rate 1 1 0 500
Soft Start 1 On Off On
Manual Offset 1 500 0 1000
Auto Control Mode 2 PID On / Off PID
Auto / Manual / Off 2 Auto 0 100 Off
Deadband 2 10 2 100
Autotune 2 Off Off On
Proportional Band 2 20 1 100
Integral 2 500 0 9999
Rate 2 1 0 500
Soft Start 2 On Off On
Manual Offset 2 500 0 1000
