Address Description Range Comments
40022 Parity 0-2
0 - NONE
1 - EVEN
2 - ODD
40023 Modbus Slave Address 0-255 Expressed as an integer number
40024 Reserved
40025
GFEP Alarm Threshold for
Ckt 1
30-150
Expressed as an integer number
(in mA e.g. 75 = 75mA)
40026
Low Current Alarm for
Ckt 1
0.0- 100.0
Expressed as an integer number in tenths of
Amp (e.g. 250 = 25.0 Amp)
40027
HI Current alarm for
Ckt 1
0.0 – 100.0
Expressed as an integer number in tenths of
Amp (e.g. 250 = 25.0 Amp)
40028 GFEP Alarm behavior Ckt 1 0-3
0 - Alarm Only, non latching
1 - Alarm and Trip, non latching
2 - Alarm and Trip, Latching
3 - Alarm Only, Latching
40029 Reserved
40030
GFEP Hi Alarm Threshold for
Circuit 2
30-150
Expressed as an integer number
(in mA e.g. 75 = 75mA)
40031
Low Current Alarm for
Circuit 2
1.0- 100.0
Expressed as an integer number in tenths of
Amp (e.g. 250 = 25.0 Amp)
40032 HI Current alarm for Circuit 2 0.0 – 100.0
Expressed as an integer number in tenths of
Amp (e.g. 250 = 25.0 Amp)
40033 Soft Start Circuit 1 0-1
0 - No
1 - Yes
40034 Soft Start Circuit 2 0-1
0 - No
1 - Yes
40035 GFEP Alarm behavior Ckt 2 0-3
0 - Alarm Only, non latching
1 - Alarm and Trip, non latching
2 - Alarm and Trip, Latching
3 - Alarm Only, Latching
40036
Temperature sensing
( Circuit 1)
0-4
0 - Controller will take the highest reading out of
two RTDs (1A and 1B)
1 - Controller will take the lowest reading out of
two RTDs (1A and 1B)
2 - Controller will take the average reading out
of two RTDs (1A and 1B)
3 - Controller will use RTD # 1A
4- Controller will use one RTD 1A to control both
circuits
40037 Temperature sensing (Circuit 2) 0-3
0 - Controller will take the highest reading out of
two RTDs (2A and 2B)
1 - Controller will take the lowest reading out of
two RTDs (2A and 2B)
2 - Controller will take the average reading out
of two RTDs (2A and 2B)
3 - Controller will use RTD # 2A
40038 Default output 1 0-100% Expressed as an integer number (e.g. 75 = 75%)
40039 Default output 2 0-100% Expressed as an integer number (e.g. 75 = 75%)
40040 Reserved
40041 Reserved
