3. Firmly grasp the headlamp bulb socket assembly and
rotate counterclockwise to remove from the housing.
4. Disconnect the bulb from the electrical connector and
then connect the replacement bulb.
CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with any oily surface, clean the
bulb with rubbing alcohol.
5. Install the bulb and connector assembly into the head-
lamp housing and rotate clockwise to lock it in place.
6. Install the headlamp bulb cap in the headlamp housing
and rotate clockwise to lock it in place.
Headlamp Bulb Socket
Headlamp Bulb
446 IN CASE OF EMERGENCY
