Chuango H4 User Manual

25 26
No phone call
notication upon
sounding of alarm
Conrm that the SIM card is not in arrears
Conrm that the alarm number has been set
If you set the system to Disarm immediately after the sounding of the
alarm, there will be no phone call notication
No sound emitted from
the alarm
Check if the panel is in mute mode. You can adjust the volume through
the App
Unsuccessful pairing
between the wireless
accessory and the
alarm panel
Conrm that the operating frequency of the wireless accessory is the
same as that of the alarm panel
How long does the
remote control battery
normally last?
A CR2025 button battery usually lasts 2 years
How long does the
door/window contact
battery normally last?
Door/window contact has two pieces of 1.5V AAA LR03 batteries,
which last approximately 2 years
How long does the
PIR motion detector
battery normally last?
The PIR motion detector has two pieces of 1.5V AA LR6 batteries,
which last approximately 2 years if it was set to power saving mode
Specication
Panel
Model H4
Power Supply DC 12V 500mA
Built-in Battery 3.7 V 800 mAh Lithium Battery (BL-5B)
GSM Operating Frequency 850/900/1800/1900 MHz
WiFi IEEE 802.11b/g/n
Standby Current <100 mA
Alarm Current <300 mA
Internal Siren Volume 105 dB
Max. No. of Connectable Wireless
Accessories
10 Remote Controls, 40 Detectors/Smart
Switches
Wireless Radio Frequency Directional: 315MHz or 433MHz
Bidirectional: 868MHz or 915MHz
Casing Materials ABS Plastics
Operating Conditions Temperature: 0°C ~ +55°C
Relative Humidity<80% (No Condensation)
Size of Alarm Panel (L x W x H) 160 x 160 x 45 mm
Size of Stand (L x W x H) 80 x 80 x 10 mm
Bidirectional Remote Control
Model RC-86
Power Supply DC 3 V (1x CR2025 Button Battery)
Standby Current <4 uA
Alarm Current <10.6 mA
Transmitting Distance <80 m (Open Area without Interference)
Wireless Radio Frequency 868 MHz or 915 MHz Bidirectional
Casing Materials ABS Plastics
Operating Conditions Temperature: 0°C ~ +55°C
Relative Humidity<80% (No Condensation)
Size of Remote Control (L x W x H) 58 x 31 x 9.5 mm

Chuango H4 Specifications

General

Wi-Fi	Yes
Alarm decibels	105 dB
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Operating frequency	433 MHz
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	0 - 80 %
Number of supported remote controls	10
Number of simultaneously connected devices (max)	70
Product color	White
Housing material	Acrylonitrile butadiene styrene (ABS)
Motion sensor technology	Passive infrared (PIR) sensor
Number of remote controls	2 pc(s)
Number of door/window sensors	1 pc(s)
Alarm current	300 mA
Static current	100 mA
Battery voltage	3.7 V
Battery capacity	800 mAh
Battery technology	Lithium
