Chuango H4 User Manual

01 02
Characteristics of Smart Home System
1. Stable Transmission
Stable transmission at 315MHz or 433MHz direction frequency and at 868 MHz or
915 MHz bidirectional frequency
2. Powerful Functions
Security system and home automation 2 in 1
Supports WiFi and SIM card
Supports 5 alarm notication numbers
Supports 50 wireless accessories (10 remote controls, 40 detectors/smart switches)
3. High Level of Security
Hidden tamper switch to prevent malicious damage
Built-in 1,000,000 RF codes
105-dB siren deterrence
4. User-friendliness
Addition and removal of accessories by category
App remote control alarm system and home appliance switch control
Packaging List
Please check if the following items are contained in the package. In case of any missing
parts, please contact the distributor/retailer.
H4 panel ×1 H4-PW smart switch ×1 RC-86 bidirectional
remote control ×2
PIR-860 bidirectional
PIR motion detector ×1
DWC-86 bidirectional
door/window contact ×1
AC adapter ×1
H4 stand ×1
Double-sided adhesive
tape (Two for PIR
detector and two for
door contact)
User manual ×1PIR stand ×1

Chuango H4 Specifications

General

Wi-Fi	Yes
Alarm decibels	105 dB
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Operating frequency	433 MHz
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	0 - 80 %
Number of supported remote controls	10
Number of simultaneously connected devices (max)	70
Product color	White
Housing material	Acrylonitrile butadiene styrene (ABS)
Motion sensor technology	Passive infrared (PIR) sensor
Number of remote controls	2 pc(s)
Number of door/window sensors	1 pc(s)
Alarm current	300 mA
Static current	100 mA
Battery voltage	3.7 V
Battery capacity	800 mAh
Battery technology	Lithium
