05
Door/Window Contact
Door/window contacts are set to ‘Armed’ zone by default and are ideal for protecting
entry/exit points such as front doors, back doors, and windows. When the system is
Armed (Away Mode) and the door/window contact is triggered (magnet separated
from the transmitter), the hub internal siren will sound immediately and send a push
notication with the sensor name to its registered users.
Triggers
when ＞ 2cm
LED blinks once
Tamper Switch
The tamper switch (small black button underneath the back cover) will activate the alarm
if an unauthorized attempt is made to remove the contact from its installed location.
Low Battery Indication
If the LED indicator ashes once per 3 seconds, the battery must be replaced.
