CIARA Astro SN-6310
- 51 -
Board components shown in Figure 4.4
Item/callout
from Figure
Description
1
Internal DC power connector (2-pin ATX19V/12V)
2
CPU and chassis fan connectors (4-pin CPU_FAN, 4-pin CHA_FAN )
3
USB 2.0 connectors
4
Serial ATA 6.0Gb/s connectors (SATA6G_1~2)
5
SATA power connector (15-pin SATA_PWRCON)
6
DDR4 SO-DIMM slots
7
Serial port connector (10-1 pin COM)
8
LCD panel monitor switch header (2-pin PANEL_SW)
9
System panel connector (10-1 pin PANEL)
10
Speaker connector (4-pin SPEAKER)
11
Panel voltage selection header (VCC_PWR_SEL)
12
LVDS connector (40-pin LVDS)
13
LCD panel backlight header (8-pin LCD_BLKT_PANEL)
14
Backlight inverter voltage selection header (3-pin BLKT_PWR_SEL)
15
Intel® LGA1151 CPU socket
16
Chassis intrusion header (4-1 pin CHASSIS)
17
Internal stereo speaker header (4-pin SPK_OUT)
18
TPM header (14-pin TPM)
19
DMIC connector (5-1 pin DMIC)
20
Clear RTC RAM (2-pin CLRTC)
21
Front panel audio connector (10-1 pin AAFP)
22
RTC Battery header (2-pin BATT_CON)
23
M.2 socket 1 (WIFI)
24
M.2 socket 3
