4.4.1 Back panel connectors
1 2 3 4 5 6 7 8 9
Description
1
DC in supply
2
USB 3.0 ports
3
HDMI port
4
DisplayPort port
5
LAN (RJ-45) port
6
LAN (RJ-45) port
7
USB 3.0 ports
8
Line Out port (lime)
9
Microphone port (pink)
