Ciara-tech Astro SN-6310 - Installation of the SSD Drive

CIARA Astro SN-6310
- 31 -
1.6.5 Installation of the SSD drive
The SSD drive must be screwed to the disk bracket.
Connect the hard drive to the power supply. Then connect
one end of a SATA data cable to the hard drive.
Connect the other end of the SATA data cable to one of
the four SATA ports.
Then screw on the disk bracket to the casing with the
four included screws.
