 CIAS Elettronica S.r.l. Ed. 2.2
Installation Handbook page 32 to 43 ERMO 482
TRASMITTER TEST CONNECTOR FOR STC 95 INSTRUMENT
Term
Symbol
Function
1
13,8
Power Supply 13,8 V
2
Ground
3
S
Function Oscillator Signal OK ( 4,5 V )
4
+ 9
Internal Power Supply 9 V
TRASMITTER LEDS
N°
Symbol
Function
Default
1
Main
Main presence indication
ON
TRASMITTER CHANNELS SWITCH
N°
Symbol
Function
Default
1
DS1
Channel Selector ( 1  4 )
TRASMITTER FUSES
N°
Symbol
Function
1
F1
Power supply protection fuse battery 13,8 V
