CIAS Elettronica S.r.l. Ed. 1.5
Installation Handbook Page 56 of 57 MANTA 50 – 80
6 CHARACTERISTICS
6.1 Technical characteristics
TECHNICAL CARACTERISTICS Min Nom Max Note
Frequency:
F1 10,5GHz 10,6 GHz
F2 9,5 GHz 9,975 GHz
F3 9,2 GHz 9,5 GHz
F4 10,5 GHz 10,525 GHz
10,6 GHz
Maximum Power to emitting:
F1 500 mW e.i.r.p.
F2 25 mW e.i.r.p.
F3 25 mW e.i.r.p.
F4 500 mW e.i.r.p.
Modulation - - - on/off
Duty-cycle - 50/50 - -
Number of channels - - 16 -
Range:
MANTA 50 - 50 m - -
MANTA 80 - 80 m - -
Power supply ( V ) 11.5 V 13.8 V 16 V -
Current consumption TX in surveillance ( mA ) - 80 - -
Current consumption TX in alarm ( mA ) - 50 - -
Current consumption RX in surveillance ( mA ) - 58 - -
Current consumption RX in alarm ( mA ) - 55 - -
Intrusion alarm contact (RX) - - 100mA C-NC
Radome removal contact (TX+RX) - - 100mA C-NC
Fault contact (TX+RX) - - 100mA C-NC
Leds:
Intrusion alarm (RX) Red LED OFF - - - Not active
Radome removal (TX+RX) Red LED OFF - - - Not active
Fault alarm (TX+RX) Red LED OFF - Not active
Threshold adjustment - - - On board + SW
Weight without battery (TX) - 800 g - -
Weight without battery (RX) - 800 g - -
Diameter 205x160 mm -
Deep, brackets included 200 mm -
Working temperature -35 °C - +65 °C -
Performance level 3° -
Box protection level IP55 -
