CIAT CONDENCIAT CL2 - Page 7

EN
EN - 5 NA 15.15 B
External air flow
LIQUID Line
SUCTION Gas Line
The anti-vibration mounts are fixed to the heat pump using four HM8 screws (length 55 mm).
Condenciat Models CL2 50, 65 and 75
Anti-vibration
mount spacing
Anti-vibration
mount spacing
Option Anti-
vibration mounts
holes
for fixing the
mounts to the floor
Detail A
Position of holes for fixing
the anti-vibration mounts to
the floor
Four fixing points
(HM8 x 55 screws)
