Reading parameters
For the OPTION parameters, refer to the instructions for the "Dual zone management" option for more information. N13.61
To access rapid reading of the values measured by the heat pump sensors and probes, we recommend that you refer directly to
the measurement table accessible in the Information menu .
All of the values measured and calculated by the control are available in the Reading parameters sub-menu. Parameters
indicated by the
symbol can be accessed by the user.
No. Word sequence Values read
250
Outdoor air T° Outdoor air temperature
251
Ambient air T° Ambient air temperature
252
Ambient air T°
Ambient air temperature in zone 2
253
Corrected water setpoint Setpoint for water return to the heat pump corrected by the control
254
Corrected water setpoint
Setpoint for water supply from zone 2 corrected by the control
255 Corrected stage diff Compressor operation differential corrected by the control
256
Compressor short-cycle
protection time delay
Minimum compressor stoppage time before restart authorisation
268 LPuidsatT° LP saturating steam temperature
269 HPuidsatT° LP saturating steam temperature
271 IntechuidT° Refrigerant uid temperature measured at the indoor heat exchanger
272 Suctionuidoverheating Calculated overheating temperature at suction
273 SuctionuidT° Refrigerant uid temperature measured at the compressor suction
274 DischargeuidT° Refrigerant uid temperature measured at the compressor discharge
275 LP pressure Relative pressure of the refrigerant uid measured at the LP pressure sensor
277 HP pressure Relative pressure of the refrigerant uid measured at the HP pressure sensor
280
Int ech water return T° Temperature of water return to the heat pump measured at the indoor heat exchanger inlet
281
Int ech water supply T° Temperature of water supply to the heat pump measured at the indoor heat exchanger outlet
283
Ext ech water supply T° Temperature of water supply to the heat pump measured at the outdoor heat exchanger outlet
284
memorised int ech vol
owrate
Flow rate of indoor accelerator pump memorised at last ow rate check
290
Water supply T°
Zone 2 water supply temperature
291
DHW tank T° Water temperature inside the DHW tank
293
Pool water T° Water temperature measured (in the pool) at the pool water return
300
Int ech water
frost-free limit
Water temperature low limit to prevent the risk of the indoor heat exchanger freezing
302
Ext ech water frost-free
limit
P93
Water temperature low limit to prevent the risk of the outdoor
heat exchanger freezing
Glycol present on the
outdoor circuit
3°C
No glycol on the outdoor
circuit
37°F
303
Extechuidfrost-free
limit
P93-5°C
Refrigerant uid temperature low limit to prevent the risk
of the outdoor heat exchanger freezing
Glycol present on the
outdoor circuit
P93-9°F
-2°C
No glycol on the outdoor
circuit
28°F
305
Water return limit
heating mode
Low temperature limit for water return to the heat pump in heating mode
370
Expansion valve
opening rate
Number of electronic expansion valve half opening steps
