CIGWELD
Transmig
180
CONTENTS
Page
1. INTRODUCTION 1
1.1 Safety
1
1.2 Protective Filter Lenses 1
1.3 Welding Protection 2
1.4 User Responsibility 2
1.5 Duty Cycle 2
2. SPECIFICATIONS 3
2.1 Power Source Specifications 3
2.2 MIG Torch Specifications 3
2.3 Wire Drive Specifications 4
2.4 Plant Contents
4
2.5 Optional Accessories
4
3. INSTALLATION RECOMMENDATIONS 5
3.1 Environment 5
3.2 Location 5
3.3 Ventilation 5
3.4 Mains Supply Voltage Requirements 5
3.5 Alternative Mains Supply Voltage Connection 6
4. WIRE SPOOL HUB ADJUSTMENT 6
4.1 Standard 300mm Spool Set-up
6
4.2 Handi 200mm Spool Set-up 7
4.3 Mini 100mm Spool Set-up 7
5. SET UP FOR TRANSMIG 180 7
6. POWER SOURCE CONTROLS, INDICATORS AND FEATURES 9
6.1 POWER ON Light
9
6.2 Voltage Control Switch
9
6.3 OVER TEMPERATURE Light
9
6.4 Wirespeed Control
9
6.5 Burnback Adjustment 10
6.6 Polarity Reversal Terminals ™
6.7 Thermal Overload.... ^
6.8 Whefeeder Driver Roller Pressure Adjustment • ™
6.9 Wire Spool Brake
11
7. TWECO MIG TORCH (717579) H
7.1 Introduction "
7.2 MIG Torch Components 12
7.3 MIG Torch Consumable Parts
12
