- 35 -
Adjusting Fuel Pump Pressure
The fuel pressure is factory set @ 140 PSI. As the pump wears, it may require adjustment as
follows:
1) If your unit is not already equipped with a fuel pressure gauge, remove plug (H) and
insert a 0-200 psi gauge.
2) With the pump running, loosen jamnut (J) and turn screw (K) clockwise to increase the
pressure, CCW to decrease pressure.
3) Hold the screw (K) with a screwdriver while tightening jam nut (J).
