MC55i Terminal Hardware Interface Description
2.1 Key Features at a Glance
17
MC55i_Terminal_HD_v01.201a Page 17 of 47 2010-04-16
Confidential / Released
Audio Speech codecs:
• Half rate HR (ETS 06.20)
• Full rate FR (ETS 06.10)
• Enhanced full rate EFR (ETS 06.50/06.60/06.80)
• Adaptive Multi Rate AMR
Echo cancellation, DTMF, 7 ringing tones
Software
AT commands Hayes 3GPP TS 27.007, TS 27.005, Cinterion
Firmware update Upgradeable via serial interface.
Interfaces
Serial interface • RS-232 interface, bi-directional bus for AT commands and data.
• Multiplex ability according to GSM 07.10 Multiplexer protocol
• Baud rates from 300bps to 115200bps
• Autobauding supports: 1200, 2400, 4800, 9600, 19200, 38.400, 57600
and 115200bps
• Supports RTS/CTS hardware handshake and software XON/XOFF
flow control
Audio Analog (Microphone, Earpiece)
SIM card reader Supported SIM cards: 3V, 1.8V
Antenna Connected via antenna FME connector
Power on/off, Reset
Power on DTR line at RS232 interface or IGT_IN line at power connector
Power off • Normal switch-off by AT^SMSO or On/Off push button
• Emergency switch-off via EMERGOFF line at power connector
• Automatic switch-off in case of critical temperature and voltage condi-
tions
Reset Orderly shutdown and reset by AT command or power down signal.
Special features
Real time clock Timer functions via AT commands
Phonebook SIM card and phone
Feature Implementation
