4.5 Electrical Characteristics of the Voiceband Part
The electrical characteristics of the voiceband part depend on the current audio mode selected
by the AT command AT^SNFS. See Table 11: Audio modes.
The audio modes 4 and 5 can be adjusted by parameters. Each audio mode is assigned a sep-
arate parameter set.
Note: The parameters inCalibrate, outCalibrate and sideTone accept also values from 32768
to 65535. These values are internally truncated to 32767.
Table 20: Audio parameters adjustable by AT commands
Parameter Influence to Range Gain range Calculation
inBbcGain MICP/MICN analogue amplifier
gain of baseband controller before
ADC
0...7 0...42dB 6dB steps
inCalibrate digital attenuation of input signal
after ADC
0...32767 -
...0dB 20 * log (inCali-
brate/
32768)
outBbcGain EPP/EPN analogue output gain of
baseband controller after DAC
0...3 0...-18dB 6dB steps
outCalibrate[n]
n = 0...4
digital attenuation of output signal
after speech decoder, before sum-
mation of sidetone and DAC
present for each volume step[n]
0...32767 -
...+6dB 20 * log (2 * out-
Calibrate[n]/
32768)
sideTone digital attenuation of sidetone
is corrected internally by outBbc-
Gain to obtain a constant sidetone
independently to output volume
0...32767 -
...0dB 20 * log (sideTone
32768)
