3 Interface Description
3.1 Overview
MC55i Terminal provides the following connectors for power supply, interface and antenna:
• 6-pole Western plug (female) for power supply, ignition, power down signal
• 4-pole Western plug (female) for audio accessory, such as a handset
• 9-pole (female) SUB-D plug for RS-232 serial interface
• FME Jack (male) for antenna (Antenna interface)
• SIM card holder
Figure 1: MC55i Terminal rear view
RS-232 interface
Antenna interface
Power supply
Status LED
Audio interface
SIM card holder
