6 Full Type Approval
6.1 Cinterion Reference Setup
The Cinterion reference setup submitted to type approve MC55i Terminal consists of the fol-
lowing components:
• MC55i Terminal with approved GSM module MC55i
• Votronic Handset type
•PC as MMI
• Power Supply
Figure 16: Reference equipment for approval
For ordering information please refer to Chapter 7.
PC
Power supply
SIM
RS-232
MC5xi
Terminal
Handset
Antenna
or
50Ohm cable
to the
system simulator
ARP
