CipherLab 8200 Reference Manual

6
8200 Series Mobile Computer Reference Manual
INSTALLING PISTOL GRIP
This contoured pistol grip enables intuitive trigger-and-scan operation, which is very
helpful in scan intensive applications.
When a pistol grip is necessary, install it to the mobile computer by following these
steps:
1) Hold the mobile computer still and slide the release latch to the right to unlock the
battery cover.
2) Slide off the battery cover.
3) Insert the pistol grip into place (is like replacing the battery cover).
4) Slide the release latch to the left to lock it firmly, and turn on the mobile computer to
test the trigger.
Figure 3: Installing the Pistol Grip

CipherLab 8200 Specifications

General

IP Rating	IP54
Display Type	LCD
Barcode Scanner	Laser
Connectivity	RS-232
I/O Ports	RS-232
