8200 Series Mobile Computer Reference Manual
1.3 KEYPAD
The mobile computer is equipped with a keypad of 24 keys for system setup, user entry
and so on. The keypad comes with programmable LED backlight, like the screen. Refer to
1.4 LCD for screen & backlight settings.
Silicon rubber has been chosen for their durability and prompt feedback. The key click
can be configured through programming or via System Menu. Refer to
3.2.6 Key Click.
1.3.1 24-KEY LAYOUT
The layout of the 24-key keypad is similar to that of a telephone, which includes
alphanumeric, navigation and function keys, as well as assorted characters. Refer to
Appendix III —
Key Reference Table for color-coded keys.
Figure 4: 24-key Layout
