23
Chapter 1
Using 8200 Mobile Computer
1.7.1 INTERFACE CABLE OPTIONS
For charging via the USB cable, the standard charging current is 500 mA. However, we
recommend you to connect the power adaptor to speed up charging the battery.
If you connect the mobile computer to a USB hub, the charging current may be
insufficient. In that case, change the charging current to 100 mA after connecting the
USB cable. It will take a longer time to charge to full. Refer to
3.2.9 USB Charge
Current
.
Warning: The mobile computer is not allowed to function when it is solely on USB
power and without a battery loaded. It will display a warning message
“Battery Missing” along with an audible alert. In that case, you should
install the battery before restarting.
Figure 6: Using USB/RS-232 cable
Universal Power Adaptor
Push & release
To Next Page
