Table 6 (Continuation): Consumption data area screens�
Screen Units
CO
2
EmissionsTariff2
kgCO2
CostTariff2
COST
No�ofhoursTariff2
hours
TotalactiveenergyconsumedTariff2
kWh
InductivereactiveenergyconsumedTariff2
kvar
L
h
CapacitivereactiveenergyconsumedTariff2
kvar
c
h
TotalapparentenergyconsumedTariff2
kVAh
With the keywecanbrowsebetweenthedifferentscreens�
ThesymbolsT1andT2thatappearonthedisplayindicatetheselectedtariffandthetariffbeing
displayed,accordingtoTable 9�
