4�6�10� Maximum demand variable
OnthisscreenthevariablestointegrateintotheMaximum
Demandconceptareselected�
Thedisplayshowsthedigitsthatidentifythatcodeforthe
variabletobeintegratedaccordingtoTable 10
Table 10: Codes for maximum demand variables
Parameter Code
Activethree-phasepower 16
Apparentthree-phasepower 34
Three-phasecurrent 36
CurrentL1,L2,L3 A-ph
None 00
The keyjumpsbetweenthedifferentoptions�
Tovalidatetheinformationandgotothenextprogrammingstep,press �
4�6�11� Period of maximum demand integration
Onthisscreenthemaximumdemandintegrationperiodis
programmed�
Toenterormodifytheintegrationperiodvalue,pressthe
key
repeatedly,increasingthevalueoftheashingdigit�
Whentheon-screenvalueisthatdesired,pressthe
keyto
gotothenextdigittomodifytheothervalues�
Ifyoupressthe keyafterchangingthelastdigit,itwilljumpbacktotherstdigitsoyou
canmodifythepreviouslyprogrammedvaluesagain�
Theintegrationperiodmayrangefrom1to60minutes�
Tovalidatetheinformationandgotothenextprogrammingstep,press �
Ifthevalueenteredisgreaterthanthemaximumprogrammingvalue,thedigitsashfor2
secondsandtheprogrammedvalueisdeleted�
31
Instruction Manual
CVM-C5
