4�6�15� Programming the digital output
TheCVM-C5digitaloutputmaybeprogrammedas:
 Pulse by n kWh or kvarh (Energy):thevaluecorrespondingtotheenergyconsumed
orgeneratedmaybeprogrammed,togenerateapulse�
Alarm condition:amagnitudemaybeassociatedwiththedigitaloutput,settinga
 maximum,minimumanddelayvalueforthetripcondition�
Ifyoudonotwishtoprogramavariable,put00andvalidatewiththe key�
 Pulse programming by n kWh or kvarh
OnthisscreentheenergycodeisselectedbasedonTable 11 for
theenergyyouwantthepulseoutputtogenerate�
The
keyjumpsbetweenthedifferentoptions�
Table 11: Codes for the different energy types�
Parameter Code
ActiveEnergyIIITariff1 31
InductiveReactiveEnergyIIITariff1 32
CapacitiveReactiveEnergyIIITariff1 33
ApparentEnergyIIITariff1 48
ActiveEnergyIIIGeneratedTariff1 49
InductiveReactiveEnergyIIIGeneratedTariff1 50
CapacitiveReactiveEnergyIIIGeneratedTariff1 51
ApparentEnergyIIIGeneratedTariff1 52
ActiveEnergyIIITariff2 55
InductiveReactiveEnergyIIITariff2 56
CapacitiveReactiveEnergyIIITariff2 57
ApparentEnergyIIITariff2 58
ActiveEnergyIIIGeneratedTariff2 59
InductiveReactiveEnergyIIIGeneratedTariff2 60
CapacitiveReactiveEnergyIIIGeneratedTariff2 61
ApparentEnergyIIIGeneratedTariff2 62
ActiveEnergyConsumed
(Regardlessofthetariffselected)
99
OnceanEnergycodehasbeenselectedandvalidatedusingthe keyyoumustenterthe
kilowattsperpulse�
33
Instruction Manual
CVM-C5
