4�6�4� Secondary current (only the model CVM-C5-IC)
Onthisscreenthecurrenttransformersecondaryisselected�
Usethe
keytojumpbetweenthetwopossibleoptionsfor
thecurrenttransformersecondary(1Aor5A)�
Tovalidatetheinformationandgotothenextprogrammingstep,press
Note: Ifthevoltageratiotogetherwiththeprogrammedcurrentratioexceedsthemaximum
powervaluethatcanbemeasuredbythedevice,itwillreturntotheprimaryvoltage
programmingstepwhenyoupressthe key
Nota :Toapplythechangetothesecondcurrenttransformerisnecessarytoresetthecomputer
4�6�5� Measurement system
Onthisscreenthemeasurementsystemtobeusedinthe
installationisselected�
The
keyjumpsbetweenthedifferentoptions
Three-phasenetworkmeasuringwitha4-wireconnection�
Three-phasenetworkmeasuringwitha3-wireconnection�
Three-phasenetworkmeasuringwitha3-wireconnectionandtransformersinan
ARONconnection
Two-phasenetworkmeasuringwitha3-wireconnection�
Phase-to-phasesingle-phasenetworkmeasuringwitha2-wireconnection�
Phase-to-neutralsingle-phasenetworkmeasuringwitha2-wireconnection�
Tovalidatetheinformationandgotothenextprogrammingstep,press
28
