1�- VERIFICATION UPON RECEPTION
Checkthefollowingpointswhenyoureceivethedevice:
 a)Thedevicemeetsthespecicationsdescribedinyourorder�
 b)Thedevicehasnotsufferedanydamageduringtransport�
c)Performanexternalvisualinspectionofthedevicepriortoswitchingiton�
d)Checkthatithasbeendeliveredwiththefollowing:
  -Aninstallationguide,
 -2Retainersforsubsequentattachmentofthedevice
Ifanyproblemisnoticeduponreception,immediatelycontactthetransport
companyand/orCIRCUTOR'safter-salesservice�
2�- PRODUCT DESCRIPTION
TheCVM-C5 devicemeasures,calculatesanddisplaysthemainelectricalparametersofthe
followinglowvoltagenetworks: single-phase,two-phase,withand withoutneutral,balanced
three-phase, with ARON measurements or unbalanced� The measurement will be taken in
RMSwiththethreeACvoltageinputsandthreecurrentinputs�
Thereare3versionsoftheteambasedonthecurrentinput:
 CVM-C5-IC,indirectmesurecorrentwithtransformers/5Aand/1A�
  CVM-C5-MC-IC,indirectmeasurecurrentwithefcienttransformersseriesMC1and
MC3�
 CVM-C5-mV-IC,indirectmesurecorrentwithtransformers/0�333V�
Thedevicefeatures:
- 3 keysthatallowyoutobrowsebetweenthevariousscreensandprogramthedevice�
- LCD Displaytodisplayalltheparameters,
- 1 digital inputtoselectthetariff�
- 1 programmable digital outputtoactasapulseoralarmoutput�
6
CVM-C5
Instruction Manual
