Toenterormodifythekilowattsperpulsevalue,pressthe
keyrepeatedly,increasingthevalueoftheashingdigit�
Whentheon-screenvalueisthatdesired,pressthe
keyto
gotothenextdigittomodifytheothervalues�
Ifyoupressthe keyafterchangingthelastdigit,itwilljumpbacktotherstdigitsoyou
canmodifythepreviouslyprogrammedvaluesagain�
Example: To program 500 Wh per pulse: 000.500
To program 1.5 kWh per pulse: 001.500
Oncethedesiredoptionhasbeenprogrammed,pressthe keytovalidatetheinformation
andtherebynishprogrammingthedevice�
Maximum programming value: 999999 KWh.
Minimum programming value: 000.001 KWh.
 Programming by alarm condition
Onthisscreentheparametercodeforwhichyouwantanalarm
tobegeneratedisselected,basedonTable 12�
The keyjumpsbetweenthedifferentoptions�
Table 12: Parameter codes for alarm programming�
Parameter Code Parameter Code
VoltagePhase-NeutralL1 01 THDvoltageL3 27
CurrentL1 02 THDcurrentL3 30
ActivepowerL1 03 Activethree-phasepower 16
Inductive/CapativereactivepowerL1 04 InductiveReactivethree-phasepower 17
PowerfactoryL1 05 CapacitiveReactivethree-phasepower 18
THDvoltageL1 25 Apparentthree-phasepower 34
THDcurrentL1 28 Maximumdemand 35
VoltagePhase-NeutralL2 06 Three-phasecurrent 36
CurrentL2 07 Cosφ 19
ActivepowerL2 08 Three-phasePowerfactory 20
Inductive/CapativereactivepowerL2 09 Frequency 21
PowerfactoryL2 10 VoltageL1-L2 22
THDvoltageL2 26 VoltageL2-L3 23
THDcurrentL2 29 VoltageL3-L1 24
VoltagePhase-NeutralL3 11 MaximumdemandL1
(1)
35
CurrentL3 12 MaximumdemandL2
(1)
42
34
CVM-C5
Instruction Manual
