Table 12 (Continuation): Parameter codes for alarm programming�
Parameter Code Parameter Code
ActivepowerL3 13 PowerfactoryL3 15
Inductive/CapativereactivepowerL3 14 MaximumdemandL3
(1)
43
(1)
Parametervalidonlyifprogrammedthemaximumdemandcurrentperphase�
Inaddition,therearesomeparameters(Table 13)thatrefertothethreephasesatthesame
time(ORfunction)�Ifyouhaveselectedoneofthesevariables,thealarmwillbeactivatedwhen
anyofthethreephasesmeetstheprogrammedconditions�
Table 13:Multiple parameter codes for alarm programming�
Parameter Code
VoltagesPhase-Neutral 90
Currents 91
Activepowers 92
Reactivepowers 93
Powerfactor 94
VoltagesPhase-Phase 95
THDV 96
THDA 97
Onceanalarmcodehasbeenselectedandvalidatedwiththe keyyoumustenterthe
maximumvalueofthealarmcondition�
Themaximum value:abovethisvaluethetransistorisclosed�
Toenterormodifythemaximumvalue,pressthe
key
repeatedly,increasingthevalueoftheashingdigit�
Whentheon-screenvalueisthatdesired,pressthe
keyto
gotothenextdigittomodifytheothervalues�
Ifyoupressthe keyaftermodifyingthelastdigitthedecimalpointpositionwillbe
programmed�
Tovalidatetheinformationandproceedtoprogrammingtheminimumvalue,press �
Theminimum value:belowthisvaluethetransistorisclosed�
Toenterormodifytheminimumvalue,pressthe
key
repeatedly,increasingthevalueoftheashingdigit�
Whentheon-screenvalueisthatdesired,pressthe
keyto
gotothenextdigittomodifytheothervalues�
Ifyoupressthe keyaftermodifyingthelastdigitthedecimalpointpositionwillbe
programmed�
Tovalidatetheinformationandproceedtoprogrammingthedelayvalue,press �
35
Instruction Manual
CVM-C5
